Team Corally Fan Holder 40mm

Team Corally - Fan Holder for fan 40 mm installation:

- Two holes with Ø3mm, 49mm apart, must be drilled into the side pan (C-00180-242) on the motor side.
- The distance to the motor should be about 5mm.
- The lower fan bracket can be used as a template for drilling the holes.
- Please then lower the holes for countersunk screws.

Required accessories:

- Hex Flat Head Screw M3x35
- Steel Nylstop Nut M3
- Hex driver allen 2mm
- Hand drill M3
- Countersink drill bit
