Special design for 1:10 RC car, low profile, aluminium brushed low voltage servo, middle cover in metal, top & bottom cover in plastic, metal gear. Entry level Servo
- Operating voltage: 4.8-6.0V
- Operating speed: 4.8V-0.085sec/60°
- 6.0V-0.074sec/60°
- Stall torque: 4.8V-10kgf.cm(139oz-in)
- 6.0V-12kgf.cm(167oz-in)
- Gear Material: Stainless steel
- Horn gear spline: 25T Φ5.9
- Size: 40.8x20x26mm(1.61x0.79x1.02in)
- Case Material: Middle cover in full metal ,top & bottom cover in plastic
- Weight: 52g
- Bearing: 2BB
- Motor type: Brushed
- Operating Temperature: -15℃~+70℃
- Operating travel: ≈180±10°
- Neutral position: 1520μsec
- Frequency: 1520uS
- Refresh Rate: 333Hz
- Pules width range: 500-2500μsec
- Dead band width: 2μsec
- Connector wire length: 180mm
- Waterproof level: Dust & Water Splash Resistance
- Programmable: No
